Use the Cycling App enough and you could win!

If you're using the City's cycling app to track your routes (or even if you haven't started yet), here's some added incentive:


I asked for this very thing when I reviewed the app. You're welcome.

The contest runs from Oct 6 (yes that was two days ago but I just got the email so get off my back) to Nov 31. So you've got just under two months to amass a contest-worthy number of trips. Then you actually have until Dec 3 to send in your entry.

This is how it works: there are three contest levels for which you can be eligible depending on how many trips you do. The app itself will let you know if you're gold, silver or bronze worthy. You then send in a screen capture of your trips page to the City: email, or hashtag #TorontoCyclingApp via Facebook, Twitter or Instagram.

Open up the app now to My Trips (or install it now if you haven't yet). You'll see that gold, silver and bronze match up to 50, 35 and 20 trips. The length of the trip doesn't matter. So that's doable right? Plus there are some nice prizes, including a new bike.

I'm only at 9 trips so I've got to start using this myself.

Finally bollards on Adelaide as cycling trips soar

I got wind from the Twitter yesterday that contractors were going to start installing bollards on Adelaide last night so I made a quick detour this morning. As predicted it appeared that most of the bollards have now been installed between Bathurst and Spadina (video)

I was blown away by the shear numbers of people already biking along it. And the bollards seemed to be doing their job quite well: discouraging errant car blocking and providing some comfort to cyclists. It's nice to do a happy story now and then.

As I was taking a video of me getting lapped by cyclists rushing off to work, I saw cycling planner Lukasz Pawlowski chatting next to someone from the iconic Rotblott's Discount Warehouse. I stopped to talk to Lukasz and look in awe at the waves of cyclists passing us.

A few weeks ago, Lukasz mentioned, the Cycling Unit had done a count on Adelaide that pegged the daily number of bike trips at about 1700. And looked like it has increased even more since then. In their 2010 count at Spadina and Adelaide that number was 640. That's a roughly 300% percent increase for a bike lane pilot that only goes to Simcoe for now and up until today didn't have any protection.

Compare that to roughly 4000 daily trips for Harbord in both directions (number from Lukasz). Lukasz said he was aware there was a lot of latent demand along this corridor but was still surprised to see just how many people and how quickly people took up the route.

In my informal counts I've seen how cycling numbers were higher on Queen than on Bloor Street. As much as I'd also like to have bike lanes on Bloor, we've often glossed over the importance of bike lanes along Queen or King, perhaps because of the difficulty of installing them. But providing a continuous east-west route that incorporates Richmond and Adelaide is a huge release valve.

I encourage Jared of Cycle Toronto to take the mayoral candidates out for a ride along Adelaide and Richmond during rush hour so they can grasp just how important these protected bike lanes are to a downtown network.

Getting better data: trying out the new Toronto cycling trips app

I've been trying out the new Toronto cycling app that allows you to track your trips on your phone (if it's an iPhone or Android). While it has some nominally useful features of showing calories burned and CO2 averted (by comparing it to a car trip I imagine) the main purpose of the app (at least in this iteration) is to help the City gather data on how people cycle now, the characteristics of those people and of the trip, and how the trips change based on changes to the infrastructure.

I took it for a spin the other day on my trip to and from the dentist.

At the very least, the planners can see the kinds of routes cyclists stitch together to avoid riding on major arterials. On my trip back from the dentist I treated myself to a short section of single track (on my crappy one-speed mountain bike turned city bike) down a hill to a path alongside the Rosehill Reservoir. That got me to Mt. Pleasant (not bike-friendly) and then to Wellesley (quick stop to see the bollards); through King's College Circle; College, Shaw and some alleyways and side streets (contra-flow rulz!) to back home. A route that someone would take only with experience and practice.

You might be wondering why the City didn't just use Strava's datasets. Hamish aka "If-it-ain't-bloor-bike-lanes-it's-a-waste-of-money" Wilson, Toronto's resident "carmudgeon", asked this very question in an email rant. Good question. The short answer is that this app isn't geared towards just fredly-types on Cervelos but will also track characteristics of the type of ride (recreational, errand, commute) and of the cyclist (gender, income, comfort-level) while still keeping the data anonymous. But even aside from that, the City can't use or store data out of the country and has extra requirements with privacy laws on the security of the servers.

The Oregon Department of Transportation recently went the Strava route by purchasing a dataset that they're using in making design decisions. Their choice has been roundly criticized for using data that is not representative of most cyclists. This is perhaps where the Toronto Cycling app will do a better job of getting representative data. By having information about the people cycling they can weight the trip data based on other cycling survey.

A researcher noted in her blog, echo in the city (thanks Hamish for the link), that it's okay for ODOT to use nonrepresentative samples so long as there is transparency, "justify decisions and choices about sampling, and use the results responsibly." But, this researcher (I'll call her echo), points out that in the case of ODOT the problem is that the Strava dataset is not that it's a small sample (only 2.5% of all commuters) but that it's likely an "inappropriate sample to address the project goals". Even then, echo notes, the project can be saved. At $20,000 it's cheap so far surveys go, and could be a "great pilot to test how to go about studying cyclists’ behavior using GPS–both in terms of its strengths and limitations as an approach". It appears to me that the Toronto Cycling app will do a better job here.

But that's not to say there can't be improvements to the app or the data collection. One major one is to encourage more people to use it. I'm admittedly a bike nerd and went out of my way to install the app and remember to turn it on for every short/long trip. The City should consider offering a raffle to everyone who records X number of trips in a season, where X could be low enough to make it easy for casual cyclists to achieve. This would hopefully increase the types of cyclists that would use it. And the City should not see this as a substitute for surveys but rather a supplement.

I have high hopes that this project will prove to be useful. The developers, Brisk Synergies, are focused on technology for transportation (equitable transportation, in fact). Luis F. Miranda-Moreno, chief scientist for Brisk, has done a lot of work on cycling and pedestrian transportation, including a Montreal study with Anne Lusk on its cycle tracks: “Risk of injury for bicycling on cycle tracks versus in the street”.

I think the Toronto Cycling app—while needing some improvements—can be a useful tool for improving cycling infrastructure. While my argument is unlikely to convince Hamish, perhaps it's enough for you, my dear reader?

Serious flaws in Copenhagen study that claims to show bike lanes are unsafe

We build bike lanes to make us safer and more comfortable while riding our bikes. Cities all over the world are building painted bike lanes and separated bike lanes. Knowing whether bike lanes are actually safer is important, to say the least. The science of the safety of bike lanes, however, is a bit behind.

The science doesn't have to be perfect in order for us to take some action, but it needs to be helpful. We need to understand how research was done and how the researcher came to their conclusions. When it comes to a Danish study by Danish researcher S. U. Jensen titled "Bicycle Tracks and Lanes: a Before-After Study" we probably should not trust its conclusions that bike lanes and separated bike lanes are unsafe. Or so argues Dr. Kay Teschke, with whom I corresponded by email last winter. (Photo of woman and girl cycling on Copenhagen street by Ian)

I'm looking at this study in particular because there are competing claims to what it actually proves. There are those who have argued that Jensen's study is proof that separated bike lanes (more commonly known as cycle tracks in Europe) are dangerous. But there are also those who have argued that when read properly the study actually shows that separated bike lanes are safe (see postscript below).

I decided to get to the bottom of this and contacted Dr. Kay Teschke of the University of British Columbia to find what an expert in epidemiological research--who also conducted a large research study on cycling safety--has to say about this study. I'm reaching out to Jensen as well and will post his response if I get one.

Jensen, in his Copenhagen study, came to the controversial conclusion that cycling on cycle tracks* is less safe than cycling on streets without any cycling infrastructure. Jensen concluded:

The safety effects of bicycle tracks in urban areas are an increase of about 10 percent in both crashes and injuries. The safety effects of bicycle lanes in urban areas are an increase of 5 percent in crashes and 15 percent in injuries. Bicyclists’ safety has worsened on roads, where bicycle facilities have been implemented.

Safety is worse with bike lanes? Jensen's conclusions are counter-intuitive and don't fit well with the results of a number of other studies, as was shown in a recent meta study of scientific studies of cycling and injuries. (Doing meta-analysis is common in epidemiology, where researchers compare different studies and look for patterns.) Given that Jensen's study comes to this irregular conclusion it would be easier to trust if we had a clear idea of how he arrived there. That, however, is one of the main problems with Jensen's paper: a lack of transparency.

Black box

The main issue with Jensen's study is that it's a black box; an algorithm that he never reveals. Jensen shows us the initial numbers that he measured, then puts them into his black box and out the other end comes the inverse.

Says Dr. Teschke:

Jensen did a very elaborate analysis with lots of adjustments. It is good to take into account factors that might bias unadjusted results, but usually the first analysis is the simple unadjusted one. Jensen does not present the unadjusted results, so I calculated them based on the data presented in his paper. On page 4, he indicates that the before and after periods studied were equally long. In Table 3 on page 9, he presents the observed before and after data on crashes and injuries. He also presents expected after data, based on all the adjustments. But let’s first look at the observed, before and after. In every row, except two (Crashes Property damage only and Intersections All crashes) the observed injuries or crashes after are lower than the observed before. On page 12, he indicates that there was a 20% increase in bicycle and moped traffic in the after period. So a calculation of crude relative risks (RR) for after vs. before:

  • Bicyclists and moped riders, all injuries total:
    RR = (injuries after/traffic after)/(injuries before/traffic before) = (406/1.2)/(574/1) = 0.59
  • Bicyclists and moped riders, intersection injuries:
    RR = (injuries after/traffic after)/(injuries before/traffic before) = (285/1.2)/(353/1) = 0.67
  • Bicyclists and moped riders, on links injuries:
    RR = (injuries after/traffic after)/(injuries before/traffic before) = (121/1.2)/(221/1) = 0.46

All three of the unadjusted results in the after vs. before comparison for bicyclists and moped riders show a reduction in risk (RR=1 means the same risk after and before, RR < 1 means lower risk after, RR > 1 means higher risk after). It is very strange not to report these results in the paper. They mean that over the period studied, the risk for cyclists and moped riders went down in the period after installation of the cycle tracks.

The question that should be answered with the adjustments is whether this reduction in risk is because of the cycle tracks or whether it is just a time trend - perhaps risk also went down on routes without new cycle tracks. If the comparison streets used for the adjustments were really comparable and if all the adjustment assumptions are unflawed, then the answer to that question would be “the reduction in risk is not from the cycle tracks”. But to take the conclusion further than that and say, after all these adjustments, cycle tracks are less safe (i.e., completely reversing the crude results)? This requires a level of trust in the adjustments that is very hard to justify in my view - especially given the difficult-to-follow description of the methodology and the many assumptions involved.

So can we trust Jensen's numbers? I don't think we can. Dr. Teschke's preliminary calculation of risk based on Jensen's numbers came to a Relative Risk of 0.59 compared to a higher risk of 1 for a street without bicycle facilities. In other words, Jensen's raw numbers support the conclusion that bicycle facilities reduce risk of injury. But it would be quite odd, Dr. Teschke explains, that the final, adjusted result would show the opposite of this. Yet when the final result comes out of Jensen's black box they are just that.

Science needs to be transparent and reproducible and this study falls short of that standard.

No one study can be the final word one way or the other. In the much more studied world of health and medicine, epidemiologists are looking for consensus among studies before coming to conclusions. The Copenhagen study has too many problems to serve as the final word on bike lane safety for policy makers.


I wasn't the first blogger to question this study, I had also asked Dr. Teschke other questions about this study and how it related to what another statistician, Dr. Lon Roberts, had said about the study.

Another blogger from Texas, Jason Roberts, was also interested in understanding this controversial study better and had asked Dr. Lon Roberts for his opinion on the study. Jason linked to a simplified version of Jensen's study (called “Road safety and perceived risk of cycle facilities in Copenhagen”) that had even less information about Jensen's methodology and thus may have mislead Dr. Roberts. At least, that's my theory.

Dr. Roberts told Jason that "the Copenhagen study shows that the "likelihood an individual bicyclist will experience an accident goes down as the number of bicycle riders go up".

Furthermore Roberts says:

Using Soren’s percentages, here’s an example starting with the assumption that 10 bicyclists out of 10,000 will experience an accident over a certain period of time if there are no bike tracks:

On an individual basis, there’s a 10 out of 10,000 (or 0.1%) chance that an individual biker will experience an accident if there are no bike tracks
When the bike tracks were added, the accident rate increased by 9%. In other words, if there are 10 accidents without the tracks, the number of accidents increases 10.9 (or approximately 11). On the other hand, the number of bike riders increased by 18%, from 10,000 to 11,800. Therefore, on an individual basis the likelihood of an accident with the tracks added is now 11 out of 11,800, or 0.09%, as opposed to 0.1% without the lanes/tracks.

So Dr. Roberts is basically saying that Jensen had accounted for bicycle traffic volume when reporting the numbers (greater numbers of cyclists will always have some effect on increasing crashes/accidents). But Dr. Teschke seemed to be saying that Jensen had accounted for bike traffic. So I asked for more explanation.

I asked:

In your discussion paper you listed RR = 1.10 versus Jensen's estimates of expected injury rates. Does this mean that Jensen had taken into account bicycle traffic volume when he provides an estimate of injuries +10% (Table 3)? I'm assuming you added .10 to 1?

And if Jensen has already accounted for bicycle traffic in his estimate I'm confused about Roberts' calculation. Is Roberts' accounting for the denominator a second time?

Dr. Teschke responded:

Jensen’s formulas indicate that he did take bicycle and moped traffic into account - in more than one direction. He also took motor vehicle traffic into account. The reasoning for the latter is not clear to me. Perhaps he is saying that if MV traffic volumes went down after cycle tracks were installed, you would expect fewer crashes. But if lower MV traffic is one of the pathways to lower bike and moped crashes on cycle track routes, that is a good thing, not something to be adjusted out of the analysis.

You are right, I added .10 to 1.

Robert’s calculation is not very clear to me. It does seem to assume that Jensen did not take bicycle and moped traffic into account. The formulas in Jensen’s paper suggest he did.

But it is easy to be confused about what Jensen did. It is not clear what alpha and beta are, or how he chose the values for those parameters. He mentions “Danish crash prediction models” but does not provide a citation. Although he laid out the formulas for the traffic adjustments, he did not do the same for either the trend or regression-to-the-mean adjustments. When an adjustment method reverses the unadjusted result, it is important that the method be clear and highly defensible.

I also asked Dr. Teschke why Jensen's study wasn't included in their literature review.


  1. Why was this one missed from the lit review? Did it not meet the criteria?

Dr. Teschke:

You are right, we didn’t include the Jensen study in our literature review, because it did not meet our criterion of being published in the peer-reviewed literature. It was published in conference proceedings not a peer-reviewed journal. After the review was published, many people noted that we did not include this study and, when we gave the reason, they argued that the reviews of the Transportation Research Board are more rigorous than those of many conferences, so it should be considered truly peer-reviewed.

We have referenced the Jensen study in subsequent publications, for example in the Discussion of our injury study.

I hope this is useful for some of you interested in connecting the dots between bike lanes, protected bike lanes and safety. It's not easy to dive into the data, but luckily scientists are taking subject matter more seriously.

Two-way cycle tracks are fine, just look to Montreal

Rue Berri cycle tracks

Are two-way (or bidirectional if you prefer) protected bike lanes "dangerous"? Some of the opposition to the Harbord proposal are fomenting fear and doubt by claiming as much. There's even a "No Danger Lanes" facebook page decrying the bidirectional for Harbord.

Let's put this question a different way. Has there been an uproar in Montreal about death and destruction because of their plentiful bidirectional bike lanes? Has there been a bloodbath that we've been ignoring?

I might have missed something but I think not. Montrealers seem to be plenty angry at their corrupt mayors but when it comes to their bidirectional cycle tracks (aka protected bike lanes), the overwhelming majority of people seem to be happy and there's been no outcry of cyclists getting injured on them in great numbers.

And Montreal isn't alone. Cycling nirvanas like Amsterdam also have bidirectional cycle tracks and the people seem to be happy with them, or at the very least accepted them.

A bi-directional path. Photo: Mikael Colville-Andersen.

So let's use some common sense. Two-way cycle tracks are not dangerous. They are safe and people are comfortable with them.

Is this a bloodbath you were looking for?

You might say, "Well that's all well and good but what about this Montreal blogger who seems to have discovered the dangers of Montreal bidirectional?"

Let's take a look.

This Montreal blogger is David Beitel who made a claim that the cycle tracks in Montreal have an "elevated risk" of cycling accidents. He pointed out that two of the cycle tracks had the second and third highest number of accidents between cyclists and drivers in Montreal out of all streets.

You might exclaim: holy crap, why are all these cyclists getting injured on cycling infrastructure? Let's rip it all out!

But let's not get carried away. Beitel falls for a common error: he provides absolutely no context to the data; no denominator to put his data into proper perspective. The denominator we need here is the number of people cycling on each street.

Without a denominator of the cycling traffic volume, we might as well just conclude that riding on a highway like the Gardiner Expressway is the safest. Highways typically have very few cycling crashes. But they also usually have next to zero cyclists using them. Because it's illegal.

Beitel's approach cannot avoid absurd conclusions.

When we take into account cycling traffic volumes we would find that the cycle tracks in Montreal, such as De Maisonneuve and Berri, are actually not dangerous at all. When cycling traffic increases we will typically see some uptick in the number of car-bike collisions. And we realize that even though a highway may have zero cyclist colliding with drivers, it might be because there were no cyclists there.

So Beitel's conclusions are junk and anyone here in Toronto who references Beitel as "proof" of the danger of bidirectional is plain wrong. If you're curious you can read a bit more about this in the Evidence Training Guide created for cycling educators by the Cycling in Cities group at the University of British Columbia (particularly pages 2, 3 and 43 in the sidebar).

Bidirectional cycle tracks are probably safer

Of the scientific evidence we do have, we could make a safe bet that 1) bidirectional cycle tracks are probably safer than riding on the road and 2) cycle tracks in general are safer than bike lanes.

In a study headed up by Harvard's Dr. Lusk, it found that Montreal's two-way cycle tracks were shown to be "either lower or similar injury rates compared with bicycling in the street without bicycle provisions".

Lusk found that Rue Berri (as pictured above) had a lower risk (0.48) than the reference street of Denis. Reference streets are always considered to be 1 for comparison purposes. Being below one means a street is safer than the reference.

Overall, the study found that the cycle tracks they studied (all of which were bidirectional) had a 28% lower injury rate. Lusk concluded that their "results suggest that two-way cycle tracks on one side of the road have either lower or similar injury rates compared with bicycling in the street without bicycle provisions. This lowered risk is also in spite of the less-than-ideal design of the Montreal cycle tracks, such as lacking parking setbacks at intersections, a recommended practice."

Cycle tracks (one and two-way) are safer than the road

Cycle tracks in general are safer than both riding on the road or even riding in a painted bike lane. The following diagram from UBC's study of injuries and bike infrastructure describes it well:

Cycle tracks beat all the other options for on-road infrastructure by a mile.

Where possible, build unidirectional otherwise bidirectional works

This all being said, the cycling infrastructure guides are now usually recommending unidirectional over bidirectional. Vélo Québec's Planning and Design for Pedestrians and Cyclists, for instance, says (p. 80):

"On-road bike paths should preferably be unidirectional. Bi-directional paths offer effective safety between intersections but complicate traffic at intersections. In fact, they increase the number of conflict points between bicycles and turning vehicles."

"Preferable" but not always possible.

This is fine in an ideal world. But we live in a world with physical and political constraints. We don't have the political sway to force politicians to ignore merchants and take out all the parking on any of our major arterials. Bidirectional is seen as a compromise: cyclists get something safer, more comfortable and merchants get to keep some on-street parking. For instance, Councillor Vaughan has publicly stated that on Harbord it is bidirectional or nothing:

“The bi-directional protects the parking that is needed,” says Vaughan. When asked for specific numbers his assistant helps out: “Right now there are 48 parkings spots – and with the bi-directional plan, we are trying to salvage 95 to 98 per cent of parking.” The unidirectional plan would take out all of the on-street parking.

“If the choice is bi-directional or nothing then bi-directional is safer,” says Vaughan.

So we are fighting for bidirectional on Harbord and possibly on more streets in the future with similar constraints. And we will work with traffic planners and the community to make them as safe as possible. There are number of tools at the planners' disposal: separate light phases, improved sightlines, markings through the intersections, signage, bump-outs and so on.


Motorist impunity and the fear of cycling

Memorial banner

As the Toronto Star reports, Initial reports of the crash that killed Tom Samson indicated that he had run a red light. The police and prosecutors have now stated they do not believe Samson ran a red light; instead, they believe he had stopped, properly, to make a left turn when a van hit him from behind. The Star reports, quote, "It’s unclear what prompted the change."

Infographic: how cyclists will go out of their way to travel on comfortable bike lanes

Thanks to Iain Campbell for this great infographic "Two Wheeled Traffic, or why bike lanes work"! It shows the bike traffic volume relative to the size of the road. Thus a street like St. George has only two car lanes but carries many more cyclists than nearby Queen's Park/University with its 8 lanes. Iain's data came from the City's 2010 Bike Cordon Count, which counted bike traffic into and out of downtown over 24 hours.

Iain's infographic provides a strong visual of how bike lanes are a much stronger magnet for cyclists than the importance of a road for car traffic. It strongly suggests that people will go out of their way to travel on a more comfortable, less stressful street with bike lanes. This is why I believe that separated bike lanes on Richmond and/or Adelaide will be a big draw for people of all ages, shapes and sizes.

More evidence that Helmet Laws don't make us safer

Today we learned that U of T researcher Jessica Dennis found helmet laws do nothing to reduce rates of hospitalization for head injury. We can add this to the other studies that have successfully questioned the usefulness of helmet legislation.

There has been a lot of confusion between statistics that show that helmets reduce head injuries and helmet laws which are designed to force everyone on a bike to wear a helmet. While helmets arguably reduce head injuries (although even here there is some contra-evidence), the fallout of helmet laws have been unclear at best and negative at worst. Dennis' study focused on rates of hospitalization across Canadian provinces and compared provinces that implemented helmet laws to those that didn't with their relative hospitalization rates for head injuries. They found little evidence that helmet laws did much to reduce injuries across a population.

Rates of hospitalizations for any cycling-related injury decreased by 28% (95% CI 22.8-33.2) among individuals younger than 18 in provinces with helmet laws and by 22.3% (95% CI 15-29.6) in areas without the laws, "suggesting fewer young cyclists, improvements to cycling safety, or a change in hospital admission policies," according to the researchers.

Hospitalizations for any cycling injury among adults hovered around 10 per 100,000 person-years in provinces with and without the helmet laws, with no significant differences seen.

Despite these decreases, the segmented regression analysis found no "meaningful changes" on hospitalization for head injury.

This study had a narrow focus on just hospitalization and didn't take into account whether people were discouraged from cycling because of helmet legislation. The Ontario Coroner's report on cycling deaths, however, also noted that before implementing a helmet law that the negative effects on cycling need to be also taken into consideration. One problem they found in their review of deaths due to head injuries was that the rate of helmet wearing for young cyclists was much lower than for adults even though helmets are mandatory for under 18 cyclists!

Some research exists which suggest that the health benefits of helmets may be outweighed by the detrimental effects on overall health in the population through the decrease in cycling activity in jurisdictions where helmets have been made mandatory.

The Coroner stressed that because of the possible negative health effects of a helmet law that the Province undertake an evaluation that begins "with a critical appraisal of the existing literature from jurisdictions in which mandatory helmet legislation has been implemented, and the collection of high-quality baseline data on cycling activity in Ontario."

I'm a pragmatic person that thinks that helmet promoters and helmet pro-choicers can co-exist here. I'll happily not bug you for choosing to wear a helmet (or for not wearing one while driving) while taking for myself the freedom to choose when and where I'll wear a helmet. A helmet is like a talisman. It may provide some protection in a limited fashion to a small part of your body, but it has little to no usefulness when forced on a whole population.
